¶ Which M-Series model is this guide for?
If the badge on the crate does not say M2 or M3 (Pro / Max / Ultra), stop. A G2 galvo, a Cloud desktop, or an Mcore is a different conversation. This wiki is the gantry table I actually run.
¶ Current family map
| Model | Officially listed source/bed distinction | Wiki sections that normally apply |
|---|---|---|
| M2 | 800 W fiber; 620 × 620 mm bed | Fiber CNC + handheld + fitted accessories |
| M2 Pro | 1,200 W fiber; 620 × 620 mm bed | Fiber CNC + handheld + fitted accessories |
| M2 Max | 800 W fiber; 1,380 × 920 mm bed | Fiber CNC + handheld + fitted accessories |
| M2 Ultra | 1,200 W fiber; 1,380 × 920 mm bed | Fiber CNC + handheld + fitted accessories |
| M3 | 800 W fiber + 80 W CO₂; 620 × 620 mm bed | Fiber/CO₂ CNC + handheld + fitted accessories |
| M3 Pro | 1,200 W fiber + 80 W CO₂; 620 × 620 mm bed | Fiber/CO₂ CNC + handheld + fitted accessories |
| M3 Max | 800 W fiber + 130 W CO₂; 1,380 × 920 mm bed | Fiber/CO₂ CNC + handheld + fitted accessories |
| M3 Ultra | 1,200 W fiber + 130 W CO₂; 1,380 × 920 mm bed | Fiber/CO₂ CNC + handheld + fitted accessories |
| M800 | 800 W fiber welder/source product | Source/handheld workflows where the hardware matches |
| M1200 | 1,200 W fiber welder/source product | Source/handheld workflows where the hardware matches |
Source: current official Gweike M-Series product page. Product specifications and bundles can change; your order, nameplates, source/head manuals, and serial-number configuration take priority.
¶ What the suffixes do not tell you
A model name alone does not prove chiller, source manufacturer/firmware, head revision, compressor, rotary, visual-alignment accessory, regulator/fittings, region-specific electrical arrangement, or mLaser/configuration version. Record those separately.
¶ Explicitly out of scope
Gweike G1/G2/G3/G6/G7, MCore, Cloud/Cloud Pro/Cloud RF, NOX, LF-series machines, and generic third-party fiber welders are not covered. Do not use an M-Series axis parameter, connection method, LightBurn statement, focus gauge, process row, or service procedure on them.
¶ How to use a page safely
Read the “Applies to” and “Evidence” strip at the top. A procedure marked “M-Series” still requires you to confirm the fitted source, head, process, and accessory. Exact electrical, gas, focus, and service values should always come from documentation for your delivered configuration.
